Versatile Lap Pool - 400 Series

400 OS and 480 S models

Versatile lap pool key features

  • Paddlewheel water current
  • Flat bottom and wide open for more exercise and therapy versatility

400 OS

  • One-piece design
  • 42″ (107cm) water depth
  • 18″ (46cm) deep water current

480 S

  • Four-piece design
  • 48″ (122cm) water depth
  • 28″ (71cm) deep water current

See customer reviews of our 400 Series pools

The 400 Series versatile lap pool has a flat floor for extreme versatility and function, making it ideal for exercise, entertaining and relaxation. The smooth paddlewheel water current spans the width of the pool and has 100 adjustable speeds to accommodate any ability level.

400 OS

This pool floor has a 42″ (107 cm) uniform depth and 18” (46cm) deep water current.

480 S

The 480 S has a 48″ (122cm) water depth and 28″ (71cm) deep water current. The sectional design can be assembled at the SwimEx factory or delivered in pieces for tight access.

The SwimEx 480 S – power and performance in one ultimate resistance swimming pool.



While a 400 series swim spa was being installed for a customer in Coronado, CA, they tested the SwimEx paddlewheel current (on a low speed). Notice how it spans the full width of the pool.

400 S resistance swimming pool
  • Pre-installed inlet and outlet fittings
  • Stainless steel electropolished front and rear grates (grates are NSF listed for suction entrapment)
  • 5hp electric motor
  • Custom-fit thermal blanket
  • Start-up treatment and test kit
  • Annual maintenance kit
  • Water vacuum
  • Filtration system (5.5kW electric heater, 1hp pump, 75 sq ft (6.9 m2) cartridge filter)
  • Rear emergency shut-off bar
  • Non-skid floor surface
  • Recessed ladder with stainless steel handrails
  • 2 stainless steel front handrails
  • Swim arrow with choice of color

Technical components can vary to local standards.

For more information visit our features and options page.

400 OS

  • Pool size: 17’ 9” x 7’ 7” x 4′ 10″ (5.40m x 2.31m x 1.52m)
  • Water dimensions: 11′ 9″ x 6′ 3″ (3.58m x 1.9m)
  • Pit size: 20′ x 12′ x 4′10″ (6.1m x 3.66m x 1.47m)
  • Pool weight with equipment: 3,200 lbs (1451kg)
  • Pool volume: 2,600 gal (9841 liters)
  • Pool filled weight: 25,000 lbs (1,133kg)
  • Load bearing: 425 lbs sq ft (2,074.31 kg/m2)

480 S

  • Pool size: 18′ 3.5″” x 7’ 8” x 5’ 10.5” (5.36m x 2.34m x 1.79m)
  • Water dimensions: 11′9″ x 6′3″ (3.58m x 1.9m)
  • Pit size: 20′ x 12′ x 5′10″ (6.1m x 3.66m x 1.78m)
  • Pool weight with equipment: 3500 lbs (1587kg)
  • Pool volume: 3200 gal (12,112 liters)
  • Pool filled weight: 31,000 lbs (14,061kg)
  • Load bearing: 460 lbs sq ft (2245 kg/m2)

400 OS and 480 S

  • EDGE touchscreen monitor to program and display your workout
  • 7.5hp drive system for faster water speeds
  • Ozone or UV water treatment
  • Custom pool and coping colors
  • Custom waterline tiles
  • In-pool fiberglass stairs with stainless steel handrail (vs standard recessed steps)
  • Natural gas or propane heater vs standard electric heater
  • Hardtop safety cover
  • Manual security cover
  • 2 stainless steel side handrails
  • Underwater lights
  • Hydrotherapy jet system with up to 12 jets (includes 2hp pump and controller)

480 S

  • 8-piece multi-sectional design for access into tight areas
  • 2′ (61 cm) extension increasing pool length (up to a maximum of three 2′ extensions)
  • Assembly of pool at factory

For more information, see features and options page.

Also see our section on pool operation and maintenance.
